Massive Pericardial Effusion and Pericarditis Following Coronary Artery Bypass Graft: Current Evidence and Review of Literature Volume 63- Issue 4

Sri Harsha Kanuri*, Vraj Patel, Muhammad Hassan Naeem Goraya and Gagandeep Grewal

• Merit Health Wesley Health Center, Hattiesburg, MS, USA

Received: October 17, 2025; Published: October 23, 2025

*Corresponding author: Sri Harsha Kanuri, Merit Health Wesley Health Center, 1501 Hardy Street, Hattiesburg, MS 39401, USA

DOI: 10.26717/BJSTR.2025.63.009922

Abstract PDF

Introduction: Pericardial Effusion (PE) is accumulation of fluid in serous outer membranes of the heart. It is rarely reported as a postoperative complication following cardiac surgery. It can be early or late onset and is provoked by variety of risk factors. Some reports suggest that increasing age and Coronary Artery Bypass Graft (CABG) were negatively associated with development of PE. We present a case of pericardial effusion and pericarditis following CABG in an elderly patient.
Case Presentation: We present a case where an 80-year-old male with a past medical history of Hypertension, Atrial fibrillation, and CAD presented with progressive shortness of breath. His presentation followed coronary artery bypass graft 3 weeks ago. Echocardiogram confirmed the presence of moderate to severe pericardial effusion without pericardial tamponade. Due to severity of PE, cardiothoracic surgery was consulted to perform a pericardial window to drain the fluid. A total of almost 300 cc fluid is drained. Following which patient recovered with improvement of shortness of breath and was discharged.
Discussion: Pericardial effusion after cardiac surgery is an unusual post-operative complication that can occur following cardiac surgery due to inadvertent damage to the pericardial membrane, or due to immune mediated phenomenon. Resultantly, it causes inception of fluid accumulation, pericardial thickening and constrictive pericarditis. It can present with features of cardiac tamponade based on the amount of fluid piling and other systemic factors present. Echocardiographic visualization of pericardial fluid warrants immediate drainage through creation of pericardial window, otherwise it can precipitate drastic clinical sequelae.
Conclusion: With this case report, we would like to emphasize the significance of this clinical phenomenon that can occasionally arise following cardiac surgery. Prompt recognition and treatment can result in better prognosis, other it can lead to intended clinical consequences and increased morbidity and mortality in elderly population.

Abbreviations: PE: Pericardial Effusion; CABG: Coronary Artery Bypass Graft; COPD: Coronary Artery Disease; PAF: Paroxysmal Atrial Fibrillation; CAD: Coronary Artery Disease; ED: Emergency Department; CCU: Cardiac Care Unit; RV: Right Ventricle; ESR: Erythrocyte Sedimentation Rate; CRP- Hb: Oxidative Hemoglobin; Meth-Hb: Methoxy Hemoglobin; TTE: Transthoracic Echocardiography; TEE: Transesophageal Echocardiography; ADH: Anti-Diuretic Hormone

Pericardial Effusion (PE) after cardiothoracic surgery is not that common. However it has been reported occasionally in few case reports [1-4] In a prospective follow up study, where they analyzed 1300 patients for 2 years, PE and cardiac tamponade were present in 6.2% and 4.1% respectively [5,6]. Few research studies have reported the incidence to be as low as 1-2%. Pertinent risk factors and autoimmunity might be the triggering factors for materialization of this clinical entity. Here, we a present a rare case of pericardial effusion after cardiac surgery.

Patient is an 80-year-old male with a past medical history of hypertension, COPD (Chronic obstructive pulmonary disease), PAF (Paroxysmal Atrial Fibrillation), CAD (Coronary Artery Disease) presenting to the ED (Emergency Department) with shortness of breath. He is status post coronary artery bypass grafting x 4 done on 7/8/2025. He states he has been having shortness of breath for couple weeks, but in the last 2 days it got progressively worse. Since post CABG discharge 3 weeks ago but endorses progressive dyspnea with minimal exertion warranting ED presentation today. He states that shortness of breath is constant even at rest. SOB is worse when he sits up but improves when he lies flat. He is on 4 L oxygen at nursing home. On presentation to the ED, he was tachypneic and placed on 6 L oxygen via nasal cannula. His past medical history is significant for paroxysmal atrial fibrillation managed by Beta blockers, Diltiazem and Eliquis. Bedside echocardiogram was evident for pericardial effusion. Patient transferred to CCU (Cardiac Care Unit) for close observation, monitoring and further evaluation. Cardiologist was consulted.

Echocardiography revealed Ejection Fraction (EF) is 60 to 65% with no diastolic RV (Right ventricle) collapse along with moderate to large pericardial effusion without tamponade. Since patient has elevated ESR (Erythrocyte Sedimentation Rate) and CRP (C-Reactive Protein) start colchicine 0.6 mg twice daily is started for his pericardial inflammation. Cardiothoracic surgery is consulted for consideration of pericardial window and it was performed on 08/03/2025. Over 200cc sero-sanguineous fluid from the pericardium. The fluid was collected and sent for the usual analysis and cultures. Pericardial drain was attached to Pleur-evac suction. Patient tolerated procedure well and was transported to CCU in stable condition. Broad spectrum antibiotics were started based awaiting the culture results. Overnight another 90cc of fluid was drained from the pericardial drain. Following the procedure his shortness of breath decreased considerably and he was discharged to his nursing facility (Figure 1).

Figure 1.

We present a clinical case of pericardial effusion in the elderly patient that underwent CABG 3 weeks ago. Pericardial fluid accumulation occurring earlier within 1-5 days of surgery is regarded as early PE as compared to late PE occurring within 7th post-operative day- 6 months’ time-period [7]. Pertinently, last PE effusions tend to be loculated secondary to transpiration of pericardial adhesions and scarring, thus paving the way for regional fluid clustering. Unexpected pericardial manipulation and subsequent local inflammation with blood pooling might be triggering events for kick-starting the evolution of PE following cardiac surgery. The typical risk factors for encountering PE include younger age, healthy cardiac status, higher pre-operative hemoglobin and heart valve surgery [7]. Additionally body surface area ≥ 1.28 m2, preoperative liver dysfunction, New York Heart Association class III/IV, left ventricular end-diastolic diameter z score ≥ 0.55, hypertension, immunosuppression, pulmonary thromboembolism, renal failure, heart transplant, aortic aneurysm surgery, and anticoagulant use were also postulated [8,9]. Older age group (60-69 years) were less likely to develop PE following cardiac surgery as compared to younger people [7]. A plausible explanation for this age difference might be due to stronger immune response and higher amount of pro-inflammatory cytokines in the younger population as compared to older age population [7].

Furthermore, PE is more likely associated with heart valve surgery and less likely with CABG) [6,10]. The increase incidence of atrial fibrillation following cardiac surgery and subsequent usage of anticoagulants triggering intra-pericardial bleeding might provide a explanation for heightened risk of developing PE [11]. Moreover, early removal of pericardial drains (postoperative-day 1) to minimize the risk of infections also seem to elevate the propensity to develop PE [12]. Pericardial effusions are initially small, but they slowly progress to become massive within approximately 2 weeks [9]. Pericardial effusion can be totally asymptomatic, while other cases might present classic features of pericardial tamponade such as lower cardiac output, hypotension, tachycardia and signs of right heart failure [9]. Other presenting symptoms can include chest pain, dyspnea, malaise, edema abdominal pain, nausea and vomiting [9]. Persistant pericardial effusions were sometimes associated with pleural effusions [9]. Rarely, it can present with unusual clinical manifestations such as hyponatraemia, atrial fibrillation, chylothorax and mediastinitis with trachea-oesophageal fistula [1,3,13,14]. Few cases might present with hyponatraemia, which can be explained by excessive secretion of Anti- Diuretic Hormone (ADH) secondary low cardiac output, thus causing less renal secretion, water retention and pseudo-hyponatraemia [13] (Figure 2).

Figure 2.

Alternatively, it can trigger atrial fibrillation by lipid peroxidation of the atrial cell membranes by free radicals, oxidative burst and Oxy- Hb-Meth-Hb from accumulated blood [14]. Pericardial effusion can present as chylothorax secondary to injury to lymphatic duct, thus spurring escape of lymphatic fluid into the pericardial cavity due to increased venous pressure following surgery [1]. Undrained pericardial effusion can foment irritation of the pericardial membranes, thus eliciting pericardial inflammation, adhesions and constrictive pericarditis [15]. Our patient presented with a combination of pericardial effusion and elevation of ESR (Erythrocyte Sedimentation Rate) & CRP (C-Reactive Protein), thus indicating the presence of pericardial inflammation. We managed the pericarditis in our patient with administration of Colchicine [16,17]. Mechanistically, it transpires due to autoimmune production of anti-cardiac [anti-sarcolemmal and antifibrillary] antibodies [17]. Transthoracic Echocardiography (TTE) may be sometimes inconclusive in diagnosis of PE [18]. However, in case of pericardial tamponade, classical ultrasonographic features including right atrial systolic collapse, right ventricular diastolic collapse, swinging heart and plethoric inferior vena cava might not present in most of the cases [18].

1. Accordingly, most sensitive test for diagnosis of PE is Transoesophageal Echocardiography (TEE) [18]. It will allow rapid diagnosis of PE, provides an opportunity to make a referral to cardiology and administer emergent interventions for managing this clinical condition [18]. Mild pericardial effusions tend to resolve on their own, while larger effusions might require interventions to ensure physiological cardiac output and most importantly preventing the inception of cardiac tamponade. Accordingly, moderate to severe pericardial effusions require fluid drainage either non-invasively or invasively, an undertaking that is tailored to each clinical scenario. Echocardiographic directed pericardiocentesis followed by placement of pig-tail catheter will facilitate the drainage of pericardial fluid [9]. In this regard, placement of catheter in place for longer duration of time will reduce the risk of early and late PE by 46% and 50% respectively [19]. Our patient developed a moderately severe collection of sero-sanguineous fluid (200 cc) in the pericardial space, thus necessitating the placement of pericardial window and chest-tube drain. Open cardiac surgery to drain the pericardial effusion is rarely performed. Complete closure of pericardial space with extracellular matrix following cardiac surgery is associated with reduction in the occurrence of pericardial effusion, pleural effusion and 30-day hospital readmission rate [20] (Video 1: Echocardiography Moderate to severe pericardial effusion. No Right ventricular or right atial collapse No Echocardiographic evidence of cardiac tamponade. Moderate to severe Tricuspic regurgitation. RVSP>50 mmhg).

Video.

By presenting this case of pericardial effusion with pericarditis following CABG surgery, we bring attention to this postoperative complication, which the clinicians should be cognizant. Patients with cardiac surgery and pertinent predisposing factors will have more proclivity for developing this complication. Earlier diagnosis and prompt surgical intervention paves the way for better clinical outcomes and better prognosis.

Ethical Approval and Consent to Participate

Not Applicable.

Consent for Publication

Consent taken.

Availability of Data and Materials

Not Applicable.

Competing Interests

Not Applicable.

Funding

Not Applicable.

Acknowledgements

Not applicable.

Conceptualization, S.H.K & VP; Methodology, S.H.K & S.A; Software, N.G.; Validation, N.A; Formal Analysis, N.A.; Investigation, S.H.K & VP.; Resources, N.A.; Data Curation, N.A.; Writing– Original Draft Preparation, S.H.K, M.H.G, & V.P.; Writing– Review & Editing, S.H.K., M.H.G & V.P.; Visualization, S.H.K.; Supervision, GG.; Project Administration, GG.

1. Ghorbani Ali, Roxana Kaveh, Mohammad Rezaei Zadeh Rukerd, Hanieh Mirkamali, Fatemeh Ahmadpour, et al. (2024) Chylopericardium and cardiac tamponade as rare complications of coronary artery bypass graft (CABG): A case report. International Journal of Surgery Case Reports 125: 110510.
2. Köroğlu Sedat, Ahmet Akcay, Sayarlıoğlu Hayriye, Gişi Kadir (2015) Recurrent large pericardial effusion after cardiac surgery presenting with reversible hyponatremia. J Updates Cardiovasc Med 3(1): 15-18.
3. Idu Muhammad, Chiw Yeh Lim, Kim Chai Chua (2025) Case Report: Late presentation of post-coronary artery bypass surgery pericardial effusion heralding mediastinitis with tracheocutaneous fistula. Front Cardiovasc Med 12: 1483395.
4. Tuladhar SM, Mahdad Noursadeghi, Joseph J Boyle, Jon S Friedland, Philip Hornick (2006) Tuberculous Pericardial Effusion After Coronary Artery Bypass Graft. The Annals of Thoracic Surgery 82(4): 1519-1521.
5. Ikäheimo MJ, H V Huikuri, KE Airaksinen, UR Korhonen, MK Linnaluoto, et al. (1988) Pericardial effusion after cardiac surgery: incidence, relation to the type of surgery, antithrombotic therapy, and early coronary bypass graft patency. Am Heart J 116(1 Pt 1): 97-102.
6. Kuvin JT, Nibal A Harati, Natesa G Pandian, Robert M Bojar, Kamal R Khabbaz (2002) Postoperative cardiac tamponade in the modern surgical era. Ann Thorac Surg 74(4): 1148-1153.
7. Khan NK, Kati M Jarvela, Eetu L Loisa, Jaakko A Sutinen, Jari O Laurikka, et al. (2017) Incidence, presentation and risk factors of late postoperative pericardial effusions requiring invasive treatment after cardiac surgery. Interactive CardioVascular and Thoracic Surgery 24(6): 835-840.
8. Nguyen HS, Hung Doan Thai Nguyen, Thang Duc Vu (2018) Pericardial effusion following cardiac surgery. A single-center experience. Asian Cardiovascular and Thoracic Annals 26(1): 5-10.
9. Ashikhmina EA, Hartzell V Schaff, Lawrence J Sinak, Zhuo Li, Joseph A Dearani, et al. (2010) Pericardial Effusion After Cardiac Surgery: Risk Factors, Patient Profiles, and Contemporary Management. The Annals of Thoracic Surgery 89(1): 112-118.
10. Pepi M, M Muratori, P Barbier, E Doria, V Arena, et al. (1994) Pericardial effusion after cardiac surgery: incidence, site, size, and haemodynamic consequences. Br Heart J 72(4): 327-331.
11. Khan J, Niina Khan, Eetu Loisa, Jaakko Sutinen, Jari Laurikka (2016) Increasing Occurrence of Postoperative Atrial Fibrillation in Contemporary Cardiac Surgery. J Cardiothorac Vasc Anesth 30(5): 1302-1307.
12. Andreasen J Jan, Gustav V B Sorensen, Emil R Abrahamsen, Erika Hansen Nord, Kristian Bundgaard, et al. (2016) Early chest tube removal following cardiac surgery is associated with pleural and/or pericardial effusions requiring invasive treatment. Eur J Cardiothorac Surg 49(1): 288-292.
13. Hanfy A Ahmed, Nicholas T Manasewitsch, Bryce D Beutler, Daniel Antwi Amoabeng, Mohamed Elnaggar, et al. (2020) Pericardial Effusion-Associated Hyponatremia. Case Rep Cardiol 2020: 8847666.
14. Gaudino M, Antonino Di Franco, Lisa Q Rong, Davide Cao, Carlo A Pivato, et al. (2022) Pericardial Effusion Provoking Atrial Fibrillation After Cardiac Surgery. JACC 79(25): 2529-2539.
15. Gaudino M, Amedeo Anselmi, Natalia Pavone, Massimo Massetti (2013) Constrictive Pericarditis After Cardiac Surgery. The Annals of Thoracic Surgery 95(2): 731-736.
16. Perzon O, Ariel Kenig, Yakov Fellig, Dror Mevorach (2022) Use of Colchicine for Pericardial Inflammation: Risks and Toxicities-A Cautionary Tale. JACC Case Rep 4(21): 1449-1452.
17. Dainese L, Antioco Cappai, Paolo Biglioli (2011) Recurrent pericardial effusion after cardiac surgery: the use of colchicine after recalcitrant conventional therapy. Journal of Cardiothoracic Surgery 6(1): 96.
18. Adi O, Azma Haryaty Ahmad, Chan Pei Fong, Asri Ranga, Nova Panebianco (2021) Resuscitative transesophageal echocardiography in the diagnosis of post-CABG loculated pericardial clot causing cardiac tamponade. The Ultrasound Journal 13(1): 22.
19. Tsang T S, M E Barnes, S N Hayes, W K Freeman, J A Dearani, et al. (1999) Clinical and echocardiographic characteristics of significant pericardial effusions following cardiothoracic surgery and outcomes of echo-guided pericardiocentesis for management: Mayo Clinic experience, 1979-1998. Chest 116(2): 322-331.
20. Rego A, Patricia C Cheung, William J Harris, Kevin M Brady, Jeffrey Newmam, et al. (2019) Pericardial closure with extracellular matrix scaffold following cardiac surgery associated with a reduction of postoperative complications and 30-day hospital readmissions. Journal of Cardiothoracic Surgery 14(1): 61.
