OssDsign Catalyst® Bone Graft Substitute Achieves Early Complete 360 Degree Healing (XLIF/PLF) in a Smoker with Degenerative Spondylolisthesis Volume 63- Issue 3

Zain Boghani¹ and SM Czop²*

• ¹Zain Boghani MD, Northeast Georgia Physicians Group Neurosurgery, Gainesville, GA 30501, USA
• ²SM Czop RPh, OssDsign, Inc. Columbia MD 21044, USA

Received: September 30, 2025; Published: October 10, 2025

*Corresponding author: SM Czop, RPh, OssDsign, Inc. Columbia MD 21044, USA

DOI: 10.26717/BJSTR.2025.63.009905

Abstract PDF

Circumferential fusion can be advantageous for selected patients by enhancing stability and maintaining symptom relief through longer follow-up periods. Recent publications highlighting the use of Catalyst Bone Graft Substitute fusion success in a variety of difficult and challenging patients has led to increased interest among spine surgeons, hospital administrators, and third-party payers. The following case demonstrates that the performance characteristics of Catalyst® (nanoscale surface technology, selective silicate ionic substitution, and dual pathways for endochondral and intramembranous ossification) are particularly advantageous for patients who are at higher risk for fusion failure.

Keywords: Catalyst; Synthetic Bone Graft; Silicate; Calcium Phosphate; lnterbody Fusion; Circumferential Fusion; 360-Degree Fusion

Abbreviations: VAS: Visual Analog Scale; XLIF: Extreme Lateral Interbody Fusion; PLF: Posterolateral Fusion; ICBG: Iliac Crest Bone Graft; ODI: Oswestry Disability Index

When indicated for the appropriate patient, the addition of posterior fusion to an interbody construct such as XLIF, TLIF, or PLIF, (i.e., circumferential or 360-degree fusion) may offer several advantages to posterior instrumentation alone. [1] These include the opportunity for more robust posterior decompression and enhanced lumbar stabilization. Recent publications have shown reduced compressive stresses on the interbody cage, better maintenance of overall lumbar stability, and increasing symptom relief and maintenance through much longer follow-up periods. [2-4] The use of ICBG and related morbidity has been well documented, and the use of local bone graft alone, obtained through decompression surgery, has been shown to result in lower fusion rates. [5] Patients with one or more risk factors for fusion failure have led spine surgeons to search for alternative bone graft options. [6,7] Recently the 12-month results of the first 108 patients in a multicenter registry using Catalyst® Bone Graft Substitute (OssDsign Inc, Columbia, MD) have been reported. [8] The publication generated interest among spine surgeons, hospital administrators, and third-party payers due to its “real world” cohort of patients (no restrictive inclusion or exclusion criteria, more reflective of a typical spine surgery practice). The results indicate that the performance characteristics of Catalyst® (nanoscale surface technology, selective silicate ionic substitution, and dual pathways for endochondral and intramembranous ossification) are particularly advantageous for patients who are at higher risk for fusion failure [8-10].

The patient was a 54-year-old overweight female (BMI 29.8) presenting with unrelenting back and leg pain (VAS Back-6.6/10, VAS Right Leg-6.5/10, VAS Left Leg-2.5/10, ODI 48% - severe disability) after conservative treatment, including immobilization and bed rest, spinal injections, physical therapy, and anti-inflammatory medications were unsuccessful. The patient had no previous spinal surgery but did have a history of hypertension, multiple joint disorder, an unspecified immunological disorder, and a history of mental disorder. The patient was a current smoker (cigarettes at 5 per day, number of years not given). Radiographic assessment revealed complete disc height collapse with nerve root compression secondary to degenerative spondylolisthesis at L3-L4 (Figure 1). Based on the spinal pathology and patient risk factors the surgeon determined that both interbody fusion and posterior decompression and fusion would be needed to address the patient’s symptoms. After discussing potential benefits and risks of surgery thoroughly, the patient chose to undergo surgery. The surgery consisted of a L3-L4 XLIF with a titanium cage (ATEC, Carlsbad CA) followed by posterior laminectomy and posterolateral fusion. The interbody cage was filled with 7 ccs of Catalyst Bone Graft with an additional 8 ccs placed in the bilateral gutters posteriorly along with rigid rod and pedicle screw fixation (ATEC, Carlsbad CA). Operative time was 319 minutes. There were no intraoperative or post-operative complications.

Figure 1

At the 3-month follow-up radiographs showed the instrumentation intact and in good position (Figure 2). Clinically the patients’ pain symptoms had improved dramatically (VAS Back-1.4/10, VAS Right Leg-0.4/10, VAS Left Leg-0.9/10, ODI -50%) and the patient continued physical therapy. CT scans were obtained at the next follow- up (8.2 months) due to a moderate increase in pain symptoms (VAS Back-6.0/10, VAS Right Leg-7.6/10, VAS Left Leg-1.0/10, ODI- 34%) as a result of increased activity and reduction of pain medication however the ODI had improved to moderate disability. The CT scans exhibited early and complete interbody and posterolateral fusion success (Figure 3). By the 1-year follow-up the symptoms had mostly resolved with minor residual back pain and complete resolution of radicular pain (VAS Back-2.0/10, VAS Right Leg-0/10, VAS Left Leg-0/10, ODI-26%) with a clinically significant improvement of 22 points from pre-op in the ODI. CT Scans taken at 1 year confirm complete fusion in both the interbody and posterolateral constructs seen previously (Figure 4).

Figure 2

Figure 3

Figure 4

The bone graft used for this case (Catalyst) was selected based on its handling and performance characteristics in a wide range of patients, most of which had multiple risk factors for failure. [11-13] Of particular interest with this case was fusion success in both the interbody and posterolateral constructs at 8 months in an active smoker, demonstrating rapid bone formation consistent with the dual pathways of both endochondral and intramembranous ossification. [9,10] This supports the versatility of Catalyst Bone Graft as an effective bone graft substitute in challenging patients. The combination of surgeon skill and experience in selecting the most appropriate and effective surgical procedures and adjuncts, including the choice of bone graft, resulted in a positive clinical outcome in this patient.

1. Kang YN, Ho YW, Chu W, Chou WS, Cheng SH (2022) Effects and Safety of Lumbar Fusion Techniques in Lumbar Spondylolisthesis: A Network Meta-Analysis of Randomized Controlled Trials. Global Spine J 12(3): 493-502.
2. Ramakrishna VA, Chamoli U, Larosa AG, Mukhopadhyay SC, Prusty BG, et al. (2023) A biomechanical comparison of posterior fixation approaches in lumbar fusion using computed tomography based lumbosacral spine modelling. Proc Inst Mech Eng H 237(2): 243-253.
3. Zhu Z, Xuan A, Xu C, Wang C, He Q, et al. (2024) Comparison of Clinical Efficacy in the Treatment of Lumbar Degenerative Disease: Posterior Lumbar Interbody Fusion, Posterior Lumbar Fusion, and Hybrid Surgery. Int J Spine Surg 18(6): 756-768.
4. Jiang L, Liu L, Dong L, Xu Z, Zhang X, et al. (2024) Comparison of instrumented and stand-alone lateral lumbar interbody fusion for lumbar degenerative disease: A systematic review and meta-analysis. BMC Musculoskelet Disord 25(1): 108.
5. Park DK, Roberts R, Arnold P, Kim DH, Sasso R, et al. (2019) Lumbar Spine Fusion Rates with Local Bone in Posterolateral and Combined Posterolateral and Interbody Approaches. J Am Acad Orthop Surg Glob Res Rev 3(11): e018.
6. Boonsirikamchai W, Wilartratsami S, Ruangchainikom M, Korwutthikulrangsri E, Tongsai S, et al. (2024) Pseudarthrosis risk factors in lumbar fusion: A systematic review and meta-analysis. BMC Musculoskelet Disord 25(1): 433.
7. Vaccaro AR, Chiba K, Heller JG, Patel TC, Thalgott J, et al. (2002) North American Spine Society for Contemporary Concepts in Spine Care. Bone grafting alternatives in spinal surgery. Spine J 2(3): 206-215.
8. Strenge KB, Makanji H, O’Brien J, Boghani Z, Stani T, et al. (2025) (Performance of a Novel Nanosynthetic Bone Graft (Nano-Si-Ap) in Real World Clinical Practice: Twelve Month Results of the First 108 Patients in the Propel Spine Registry. Biomed J Sci & Tech Res 62(3).
9. Conway JC, Oliver RA, Wang T, Wills DJ, Herbert J, et al. (2021) The efficacy of a nanosynthetic bone graft substitute as a bone graft extender in rabbit posterolateral fusion. Spine J 21(11): 1925-1937.
10. Bernhard JC, Presen DM, Li M, Monforte X, Ferguson J, et al. (2022) Effects of Endochondral and Intramembranous Ossification Pathways on Bone Tissue Formation and Vascularization in Human Tissue-Engineered Grafts. Cells 11(19): 3070.
11. Lazary A, Varga PP, Kiss L, Szoverfi Z, Czop S, et al. (2024) First In-Human Study with a Novel Synthetic Bone Graft, OssDsign Catalyst™ in Transforaminal Lumbar Interbody Fusion with Instrumented Posterolateral Fusion. Biomed J Sci & Tech Res 54(4).
12. Strenge KB, Archer R, Czop SM (2024) OssDsign Catalyst^®Bone Graft Performance in a Three Level Extreme Lateral Interbody Fusion (XLIF^®). Biomed J Sci &Tech Res 56(5).
13. Sadrameli S, Archer R, Czop SM (2024) Evidence of Rapid Fusion in a Two Level ACDF Patient Using OssDsign Catalyst^® Bone Graft Substitute. Biomed J Sci &Tech Res 57(2).
